39Samsung Electronics
PCB Diagram
■
Parts List (cont.)
C301,C510,C706,C903 C-CER,CHIP 1nF,10%,50V,X7R,TP,2012,- 4
C203,C204,C302,C303 C-CER,CHIP 10nF,+80-20%,50V,Y5V,TP,2012 6
C401,C705
C702 C-FILM,LEAD-PEF 10nF,10%,630V,TP,16x11x7.5mm,5 1
C703,C704 C-FILM,LEAD-PEF 4.7nF,10%,100V,TP,10x8.5x5.0mm 2
XC71,XC72 C-FILM,MPPF 100nF,10%,275V,BK,18x6x12,15 2
C111 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1
C106 C-AL 1000uF,20%,25V,GP,TP,13x20,5 1
C701 C-AL 470uF,20%,50V,GP,TP,13x20,5 1
C601 C-AL 47uF,20%,50V,GP,TP,6.3x11,5 1
C101,C102 C-AL 6.8uF,20%,450V,GP,TP,10x16mm,5 2
L101 INDUCTOR-RADIAL 5000uH,10%,8.0x11.0mm 1
X301 RESONATOR-CERAMIC 10MHz,0.5%,TP,10.0x5.0x10.0mm 1
BZ61 BUZZER-PIEZO 70dB,3V,-,2KHz,BK 1
RY71 RELAY-POWER 12VDC,0,9W,20000MA,SPST,20MS,10MS 1
SS71 SSR 12Vdc,-,2A,1mS,1mS 1
F701 FUSE-CARTRIDGE 250V,3.15A,FAST-ACTING,CERAMIC,5.2x20mm 1
F702 FUSE-RADIAL LEAD 250V,1A,TIME-LAG,-,8.5x8mm 1
CN72 CONNECTOR-HEADER 1WALL,2P,1R,7.92mm,STRAIGHT,SN,WH 1
CN73 CONNECTOR-HEADER 1WALL,3P,1R,7.92mm,STRAIGHT,SN,WH 1
CN74 CONNECTOR-HEADER BOX,3P,1R,2.5mm,STRAIGHT,SN,BLU 1
CN62 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN 1
CN71 CONNECTOR-HEADER 1WALL,2P,1R,7.92mm,STRAIGHT,SN,BLU 1
CN42 CONNECTOR-HEADER BOX,2P,1R,2mm,STRAIGHT,SN,WHT 1
CN51 CONNECTOR-HEADER BOX,14P,1R,2mm,STRAIGHT,SN 1
CN53 CONNECTOR-HEADER BOX,3P,1R,2mm,STRAIGHT,SN 1
CN61 CONNECTOR-HEADER BOX,5P,1R,2mm,STRAIGHT,SN 1
CN41 CONNECTOR-HEADER BOX,4P,1R,2mm,STRAIGHT,SN,WHT 1
CN81 CONNECTOR-HEADER BOX,3P,1R,2mm,STRAIGHT,SN,BLU 1
IC02 KA78L05AZTA(0.1A,Positive,Vol,Reg) 1
IC04 IC MICOM MB89538APF-101,MB89538APF-101,64P,+5V,10M 1
ST11 TRANS SWITCHING DC12V,-,-,-,-,-,-,12V,0.01A,-,E119 1
DSA POSISTOR DSA-332MA,2pF MAX,100Mohm,ASM-3 1
JE LEAD-WIRE UL1015 AWG#20 GRN/YEL 1
PCB 1
FT72 LS403110 1
C001 SC102M Y-CAP 7.5mm 1
Specification RemarkQ'TYDescriptionLocation No.
