PCB Diagram
41Samsung Electronics
■
Parts List
ZD21 DIODE-ZENER AXIAL;1N4749 24V,5% 1W DO-41 TP 1
IC55 IC-LOGIC ULN2003ADR,NPN,7,1W,SOP-16,ST,1000 1
L701,LED1 DIPLAY-LED ROUND,RED,TLPR5600 2
L702,LED2 DIPLAY-LED ROUND,GRN,TLPG5600 2
L703,LED3 DIPLAY-LED ROUND,YEL,TLPY5600 2
IC71 IC-RESET VOLTAGE DECTECTOR,7533,TO-92,3P 1
IC17 IC-REG 7805,TO-220,3P,KA7805 1
VA03,VA04,VA07,VA08 VARISTOR 560V,50A,0.6W,14mm,INR14D561K 6
VA09,VA201
R202 R-METAL OXIDE AXIAL;MOR 2TSJ,100Kohm,5%,2W,AA,TP,6x16mm 1
R306 R-CHIP MCR10EZH;J561,560ohm,5%,1/8W,DA,TP,2012 1
R420,R421,R422,R423,R424 R-CHIP MCR10EZH;J101,100ohm,5%,1/8W,TP,2012 7
R425,426
R420,R421,R422,R423,R424 R-CHIP MCR10EZH;J101,100ohm,5%,1/8W,TP,2012 7
R425,426
R442,R443,R701,R702,R703 R-CHIP MCR10EZH;J103,10Kohm,5%,1/8W,DA,TP,2012 13
R704,R710,R711,R712,R714
R814,R818,R908
R501 R-CHIP MCR10EZH;J1802,18Kohm,1%,1/8W,DA,TP,2012 1
R474,R475,R476,R508,R509 R-CHIP MCR10EZH;J102,1Kohm,5%,1/8W,DA,TP,2012 9
R510,R511,R513,R700
R204,R460 R-CHIP MCR10EZH;J203,20Kohm,5%,1/8W,DA,TP,2012 2
R512,R705,R706,R707 R-CHIP MCR10EZH;J221,220ohm,5%,1/8W,DA,TP,2012 4
R507,R813 R-CHIP MCR10EZH;J331,330ohm,5%,1/8W,DA,TP,2012 2
R401,R402,R404,R405 R-CHIP MCR10EZH;J472,4.7Kohm,5%,1/8W,DA,TP,2012 6
R406,R407
C202,C472,C501,C502,C503 C-CERAMIC
CHIP;CL21F104ZANC,100nF,+80-20%,50V,Y5V,TP,2012
13
C504,C505,C706,C711,C719
C721,C722,C903
C407,C707 C-CERAMIC CHIP;CL21F102ZANC,1nF,10%,50V,X7R,TP,2012,- 2
C701 C-CERAMIC CHIP;CL21B223KBNC,22nF,10%,50V,X7R,TP,2012 1
C204,C305,C306,C509,C510 C-CERAMIC
CHIP;CL21F103ZANC,10nF,+80-20%,50V,Y5V,TP,2012
7
C513,C723
C405 C-CERAMIC CHIP;CL21B471KBNC,470pF,5%,50V,UJ,TP,2012,- 1
SUB01 S3C848A S3C848A 1
MAIN MICOM TMS320LF2406A TMS320LF2406A 1
C301 C-FILM MPP;PC2J103K,10nF,10%,630V,TP,16x11x7.5mm 1
C123 C-AL RADIAL;10uF,20%,450V,RG,12.5x20mm 1
RY502,RY503 RELAY-MINIATURE F3AA012E 2
RY01 RELAY-POWER 12VDC,UKH-125 1
Specification RemarkQ'TYDescriptionLocation No.
DB98_00000A(1)_1 1/29/04 4:23 PM Page 41
