PCB Diagram
Samsung Electronics42
■
Parts List (cont.)
CN13,CN14 CONNECTOR-HEADER BOXZ,2P,1R,2mmSTRAIGHT,SN,WHT 2
DSA2 SURGE-ABSORBER
POSISTOR;DAS-332MA,2pF MAX,100Mohm,ASM-3,3300V
1
PCB PCB-BOARD 1
C001,C002,C010,C011 C-CERAMIC SCF1032(7.5mm picth) 4
C003,C004 C-FILM MPPF;RADIAL,330nF 10% 275V 2
C01 C-FILM MPPF;RADIAL,680nF 10% 275V 1
C101,C102,C103 C-AL RADIAL,560uF 105˚ 20% 2P 400V 3
C408,C409,C410 C-AL EC-DIP;RX,105˚ 47uF 50V 20% 6.3x11 3
D101 DUAL DIODE FEP30JP 1
FT00,FT01 FILTER LS615044 2
IC19 IC-REG KA78RM33,3.3V,0.5A,DPAK 1
Q803 IC-TR-IGRT IRG4BC30F,TO-220AB,1R 1
R201 R-METAL OXIDE AXIA;MOR 2TSJ,47Kohm 5% 2W 1
R301,R307 R-METAL OXIDE AXIA;MOR 2TSJ,4.7Kohm 5% 2W 2
R801 R-CEMENT 0.045ohm 5% 3W CB 12x8x25 1
X701 RESONATOR-CERAMIC 7.3728MHz 1
X501 CST,10MHZ,3P 1
IC11 IC-IPM CON TOP222P,100KHz,DIP,8P 1
IC16 KA78L05AZTA KA78L05AZTA(0.1A,Positive,Vol,Reg) 1
IC18 IC-REG KA78M15TU(0.1A,Positive,Vol,Reg) 1
R001 R-CEMENT 5RJ,200ohm(5%,5W,CB,BK,13x9x25.5mm) 1
R101 R-METAL OXIDE MOR,3TSJ,47Kohm,5%,3W,AA,TP) 1
PTC01 J512Q24E270M265 J512Q24E270M265 1
PT PT-G PT-G 1
ZD31 DIODE-ZENER AXIAL;1N4751A 1
D102,D401,D402,D403 AXIAL 1N4937 4
C117,C201,C437 C-AL READIAL;RZ,35V,47uF,6.3x11,TP 3
C107,C109,C112,C114,C115 C-AL EC-DIP;WD,25V,220uF,8x11.5,TP 9
C116,C464,C466,C471
BD01 BRIGDE-DIODE GS1B2560 1
CN04 CONNECTOR-HEADER YAW396-03AV/WHT 1
CN51 CONNECTOR-HEADER SMAW250A-04/RED 1
CN52 CONNECTOR-HEADER SMAW250A-04/WHT 1
CN53 CONNECTOR-HEADER SMAW250-06/WHT 1
CN54 CONNECTOR-HEADER YAW396-05AV/WHT 1
FUSE FUSE-CARTRIDGE 250V,20A,65TL,SLOW-BLOW,CERAMIC,6.35x31. 1
IC14 IC-REG KA7812,1A,TO-220,3P 1
IPM TR-IGBT FSAM155M60A 1
C415,C416,C417 C-CERAMIC
CHIP;CL21F104ZANC,100nF,+80,-20%,50V,Y5V,TP,2012
3
C440,C462,C702,C716 C-CERAMIC CHIP;CL21F105ZANC,1uF 2012 3
Specification RemarkQ'TYDescriptionLocation No.
DB98_00000A(1)_1 1/29/04 4:23 PM Page 42
