PCB Diagram
43Samsung Electronics
■
Parts List (cont.)
IC74 IC-LOGIC 74ALVCOM,14-SOIC 1
IC84 IC-TTL DM74ALS1034,14-SOIC 1
Q701,Q801 IC-TR BC847B,NPN,SOT-23 2
R505,R506,R516,R517 R-CHIP MCR10EZH;F331,330ohm 1/8W 1% 2012 4
ZD71,ZD72 DIODE-ZENER MMBZ52266B 2
IC73 KA431DTF KA431DTF(3-Terminal,Adjustable,Reg) 1
D103,D106 CHIP,ES1D,DO-214AC,200V 2
IC15,IC56,IC57 TLP181(GRH-TLP),SOP,TP,11-4C 3
Q202,Q301,Q302,Q502,Q503 TR-DIGITAL KRC102S,NPN,200mW,10K-10K.SOT 9
Q702
Q703,Q704,Q901
R408,R409,R410 R-CHIP MCR10EZH;J331,33ohm,1/8W,2012 3
R457 R-CHIP MCR10EZH;J1021Kohm,5%,1/8W,DA,TP,2012 1
R459 R-CHIP 30Kohm,1%,1/10W,DA,TP,2012 1
R907 R-CEMENT 0.020ohm 5% MPR 7W 1
C436 C-FILM MPP,RADIAL,PC2J104K 100nF 630V 1.5U 1
R461 R-CHIP MCR10EZH;J472,4.7Kohm,5%,1/8W,DA,TP,2012 1
R709 R-CHIP MCR10EZH;J10R0,10ohm,5%,1/8W,DA,TP,2012 1
Specification RemarkQ'TYDescriptionLocation No.
DB98_00000A(1)_1 1/29/04 4:23 PM Page 43
