Disassembly and Reassembly
Samsung Electronics4-5
No Parts Procedure Remark
4 Compressor 1) Do “1” above.
2) Open the terminal cover of compressor and
unscrew the connection terminal.
3) Disassemble the inlet and outlet pipe of
compressor by welding.
4) Disassemble the inlet and outlet pipe of
condenser by welding.
5) Loosen the three bolts of the lower part.
6) Separate the compressor.
DB98_08728A(1)_SM_1 12/20/02 3:25 PM Page 3-10
