PCB Diagrams
Samsung Electronics7-5
■
Parts List
1 C101,C102,C103(7k,9k) C-AL RADIAL,560UF,105˚,20%,400V,2PIN,BK,35x50mm 3
2 C101,C102,C103(12k) C-AL RADIAL,680uF,105˚,20%,400V,2PIN,BK,35x50mm 3
3 C115 C-AL RADIAL,RG 450V 10UF 12.5*20 TP 1
4 C408,C409,C410 C-AL RADIAL,RZ 35V 22uF 6.3x11 TP 3
5 C110,C201,C415 C-AL RADIAL,RZ 35V 47uF 6.3x11 TP 3
6 C107,C108,C109,C112 C-AL RADIAL,WD 25V 220uF 8x11.5 TP 4
7 CABLE(JU;JV;JW=RED;BLU;YEL) CBF-HARNESS
HA01, #16, 270,280,290mm,RED,BLU,YEL(COMP)(CORE #1)
1
8 CABLE(REACTOR01;02=YEL;WHT) CBF-HARNESS HA02, #16, 270,270mm,WHT,YEL(REACTOR) 1
9 CABLE(DCN01/DCN02) CBF-HARNESS HA04, #16, 140mm,BLU(DC-) 1
10 CABLE(PC01;PC02) CBF-HARNESS HA05, #20, 140mm,WHT(CON) 2
11 C303 C-CERAMIC,CHIP CL10B102KBNC 1
12 C302,C506 C-CERAMIC,CHIP CL10B103KBNC 2
13 C401,C402,C403,C404,C405,C406, C-CERAMIC,CHIP CL10C101JBNC 7
C407
14 C701,C702 C-CERAMIC,CHIP CL10C220JBNC 2
15 C202,C501,C502,C503,C504,C505,
C507,C508,C509,C703,C704,C706 C-CERAMIC,CHIP CL10F104ZANC 12
16 C203 C-CERAMIC,CHIP CL21B102KBNC 1
17 C305,C306 C-CERAMIC,CHIP CL21B103KBNC 2
18 C106,C111,C116,C204,C705,C802 C-CERAMIC,CHIP CL21B104KBNC 6
19 C414 C-CERAMIC,CHIP CL21B222KBNC 1
20 C412 C-CERAMIC,CHIP CL21B223KBNC 1
21 C113,C114,C411,C803 C-CERAMIC,CHIP CL31F105ZANC 4
22 C104,C105,C304 C-CERAMIC,DISC RADIAL,SC E 222M 10FF7 3
23 C005,C006,C007 C-CERAMIC,DISC RADIAL,SCE 103Z 14FF7 3
24 C001,C002 C-CERAMIC,DISC RADIAL,SCE 472M 14FF7 2
25 C301 C-FILM,MPET RADIAL,5TY2ARB103KAN TP 1
26 C413 C-FILM,MPP RADIAL,PC2J104K 630V TP 1
27 C004 C-FILM,MPPF RADIAL,330nF,10%,275V,TP,26x8.5x18m 1
28 C003 C-FILM,MPPF RADIAL,680nF,10%,275V,BK,31x11x21 1
29 Running capacitor(Main case+ screw) C-FILM,MPPF RMES-45H015UA 1
30 CABLE (L;N=BRN;BLU) COIL CHOKE ASS’Y
(LSA15009 ASS’Y, —mH,43X32X28mm,18Turn,CABLE)+C54
1
31 FT00 COIL CHOKE LS615014,—mH,38.5x38x30mm, 20Turn, 4PIN 1
32 FT01 COIL CHOKE LS615014S,—mH, 38.5X38X30mm,15Turn ,6PIN 1
33 L101 COIL CHOKE RADIAL,10mH(DR6.5*7.5) 1
34 L001 COIL-CHIP FCI 3216 R47K (0.47uH) 1
35 CN51 CONNECTOR-HEADER SMAW250A-04,RED,YENHO 1
36 CN52 CONNECTOR-HEADER SMAW250A-04,WHT,YENHO 1
37 CN02,CN31 CONNECTOR-HEADER YAW396A-03AV,WHT,YENHO 2
38 CN01 CONNECTOR-HEADER YAW396A-05AV,WHT,YENHO 1
39 X501 CRYSTAL-RESONATOR CST 4MHZ 1
40 X701 CRYSTAL-RESONATOR HC-49/S,12.288MHz 1
41 D301,D103,D104,D105,D106 DIODE ES1D,D0-214AC, 200V 5
42 D101 DIODE FEP30JP,FORMING 1
43 D201 DIODE US1G,D0-214AC, 400V 1
44 BD01 DIODE-BRIGE GS1B2560,FORMING 1
45 ZD21 DIODE-ZENER AXIAL,1N4749A 1
46 ZD31 DIODE-ZENER AXIAL,1N4751A 1
47 D102,D401,D402,D403 DIODE-ZENER AXIAL,1N4937 4
48 ZD22 DIODE-ZENER MMBZ5232B 1
49 FUSE FUSE 65TL 250V,20A 1
50 FUSE CLIP FUSE-CLIP FC61B 2
51 H/S(PFC) HEAT SINK 27X17.5X40 1
52 IC51 IC-MASK S3C9434XZ0-SKB4 1
53 IC83 IC-LOGIC 74HCT00D,SOP-14 1
54 IC41 IC-LOGIC LM324D 1
55 IC81 IC-LOGIC ULN2003ADR 1
56 MICOM IC-MICOM TMP88PH47F(MASK),QFP 1
57 IC15,IC21,IC31,IC32,IC54 IC-PHOTO-COUPLER TLP181(GRH-TLP),SOP,TP 5
58 IC11 IC-PWM CONTROLLER TOP222P 1
59 IC16 IC-REG KA78L05AZTA(0.1A Positive Vol Reg) 1
SpecificationDescriptionDesign LocationNo Q’TY
DB98_08728A(1)_SM_1 12/20/02 3:25 PM Page 5-10
