7-6Samsung Electronics
PCB Diagrams
■
Parts List
60 IC17 IC-REG KA78M05TU(0.1A Positive Vol Reg) 1
61 Q801 IC-TR BC847B,NPN, SOT-23 1
62 Q002 IC-TR KTA1715 1
63 Q001 IC-TR KTC2814 1
64 Q201,Q202,Q301,Q302,Q802 IC-TR-DIGITAL KRC102S,NPN,200mW,10K-10K,SOT 5
65 Q803 IC-TR-IGBT IRG4BC30F(004).TO-220AB, IR 1
66 IC14 IC-VOL REF KA431DTF(3-Terminal Adjustable Reg) 1
67 IC52,IC71 IC-VOL RN5VT45(46)CA,SOT-23-5 2
68 IPM(7k,9k) IPM PS21244-E, MIT,600V,15A 1
69 IPM(12k) IPM PS21245, MIT,600V,20A 1
70 LED2 LED_GRN SM4433(FORMING) 1
71 LED3 LED_RED SA4433(FORMING) 1
72 LED1 LED_YEL SY4433(FORMING) 1
73 PCB PCB FR4,GREEN, 220X140mm, 15/20A-MISTU 1
74 R801 R-CEMENT(S) 3RJ 0.045ohm(10%,3W,CB,BK,12x8x25mm) 1
75 R003 R-CEMENT(S) 5RJ 200ohm(5%,5W,CB,BK,13x9x25.5mm) 1
76 R411 R-CEMENT(S) 7RJ 0.015ohm(10%,7W,CA,BK,35x9.5xmm) 1
77 R501,R504 R-CHIP MCR03EZH F1802, 18Kohm, 1/10W, 1%, 1608 2
78 R502,R503 R-CHIP MCR03EZH F2402, 24Kohm, 1/10W, 1%, 1608 2
79 R205,R904,R905,R906 R-CHIP MCR03EZH J102, 1.0Kohm, 1/8W, 5%, 1608 4
80 R204 R-CHIP MCR03EZH J203, 20Kohm, 1/10W, 5%, 1608 1
81 R505 R-CHIP MCR03EZH J331, 330ohm, 1/10W, 5%, 1608 1
82 R303, R304 R-CHIP MCR03EZH J471, 470ohm, 1/8W, 5%, 1608 2
83 R305,R401,R402,R403,R404,R405 R-CHIP MCR03EZH J472, 4.7Kohm, 1/10W, 5%, 1608 11
R406,R407,R506,R508,R702
84 R306 R-CHIP MCR03EZH J561, 560ohm, 1/10W, 5%, 1608 1
85 R101,R102 R-CHIP MCR100EZH J184, 180kohm, 1W, 5%, 6432 2
86 R803 R-CHIP MCR100EZH J222, 2.2Kohm, 1W, 5%, 6432 1
87 R810 R-CHIP MCR10EZH F1002, 10Kohm, 1/8W, 1%, 2012 1
88 R113 R-CHIP MCR10EZH F1502, 15Kohm, 1/8W, 1%, 2012 1
89 R109 R-CHIP MCR10EZH F1801, 1.8Kohm, 1/8W, 1%, 2012 1
90 R805 R-CHIP MCR10EZH F2201, 2.2Kohm, 1/8W, 1%, 2012 1
91 R108 R-CHIP MCR10EZH F6801, 6.8Kohm, 1/8W, 1%, 2012 1
92 R106 R-CHIP MCR10EZH J102, 1.0Kohm, 1/8W, 5%, 2012 1
93 R207,R806,R807 R-CHIP MCR10EZH J103, 10Kohm, 1/8W, 5%, 2012 3
94 R507,R701 R-CHIP MCR10EZH J105, 1.0Mohm, 1/8W, 5%, 2012 2
95 R414 R-CHIP MCR10EZH J202, 2.0Kohm, 1/8W, 5%, 2012 1
96 R413 R-CHIP MCR10EZH J203, 20Kohm, 1/8W, 5%, 2012 1
97 R802 R-CHIP MCR10EZH J221, 220ohm, 1/8W, 5%, 2012 1
98 R412 R-CHIP MCR10EZH J222, 2.2Kohm, 1/8W, 5%, 2012 1
99 R408,R409,R410 R-CHIP MCR10EZH J330, 33ohm, 1/8W, 5%, 2012 3
100 R107 R-CHIP MCR10EZH J332, 3.3Kohm, 1/8W, 5%, 2012 1
101 R203,R302,R804 R-CHIP MCR10EZH J472, 4.7Kohm, 1/8W, 5%, 2012 3
102 R415 R-CHIP MCR10EZH J473, 47Kohm, 1/8W, 5%, 2012 1
103 R105 R-CHIP MCR10EZH J6R8, 6.8ohm, 1/8W, 5%, 2012 1
104 R110,R111,R112 R-CHIP MCR18EZH F4703, 470Kohm, 1/4W, 1%, 3216 3
105 R001, R002 R-CHIP MCR50EZH F4703, 470Kohm, 1/2W, 1%, 5025 2
106 R004 R-CHIP MCR50EZH J101, 100ohm, 1/2W, 5%, 5025 1
107 RV01,RV02 RELAY F3AA012E 2
108 RV03 RELAY-POWER UKH-12S,12VDC 1
109 R005 R-METAL OXIDE(S) AXIAL,MOR 1/4TSJ 100ohm, 5%, 1/4W, AA TP 1
110 R202 R-METAL OXIDE(S) AXIAL,MOR 2TSJ 100Kohm ,5%,2W,AA,TP 1
111 R201 R-METAL OXIDE(S) AXIAL,MOR 2TSJ 47Kohm,,5%,2W,AA,TP) 1
112 R301 R-METAL OXIDE(S) AXIAL,MOR 2TSJ 5.6Kohm,5%,2W,AA,TP) 1
113 R104 R-METAL OXIDE(S) MOR 3TSJ 47Kohm,5%,3W,AA,TP) 1
114 DSS SURGE-ABSORBER AXIAL,300V,DSS-301 1
115 DSA SURGE-ABSORBER AXIAL,500V,DSA-501 1
116 PT01 THERMISTER-PTC J512Q24E270M265 1
117 PT02 TRANS-PULSE PT_20A , 1.4mH 1
118 VA02,VA05,VA06,VA07 VARISTER 470V,0.6W,50A,14MM,INR14D471K 4
119 VA01,VA04 VARISTER 470V,0.6W,50A,14MM,INR20D471K 2
SpecificationDescriptionDesign LocationNo Q’TY
DB98_08728A(1)_SM_1 12/20/02 3:25 PM Page 5-11
