Samsung SH12VCD - ASSY DISPLAY: DB93-01601 A

Samsung Electronics7-7
7-3 ASS’Y DISPLAY : DB93-01601A
No
1
2
3
4
5
6
7
8
9
10
Description
PCB-DISPLAY
MODULE REMOCON
TACT SWITCH
C-CERAMIC
C-CERAMIC
DIODE SWITCHING
R-CARBON
CONNECTOR WAFER
C/W DIS & MODULE
HOLDER-LED
Specification
FR-1, T1.6
KSM-713TH5
KPT-1105A
CA 0A 50V 102K
CA 0A 50V 104Z
1N4148
470 1/2W 5%
SMAW200-05(WHT)
UL1007 AWG/26/11
HIPS
Q’TY
1
1
1
1
1
1
3
1
1
1
■ PART LIST
PCB Diagrams
