7. Level 2 Repair
※ C a u tio n
1) Be careful not to damage the PBA
※ C a u tio n
1) Be care of connector/cable damage
※ C a u tio n
1) Be care of PBA damage
※ C a u tio n
1) Be care of several kinds of damage
6
Detach Battery connect and the other
connectors. (7 Points, except for Front Camera
connector)
7
Detach main PBA from Front.
8
Detach other components.
Unscrew PBA 3 points.
5
MAIN Camera
SUB Camera
Battery
Motor
Ear Jack
Prox Sensor
Receiver
Detach PBA
