Samsung SR-608EV - Parts Identification and Disassembly

Samsung Electronics 9
7-2 The name of each parts and disassemble method
• Push to direction and apart to direction .
Freezer shelf
• Up the front of shelf to direction then
pull and apart to direction .
Shelf REF.
• Pull with both hands as showed.
• The height can be adjusted according to the
stored bowls.
Chilled room shelf
• Pull to the arrow direction
then up and apart at the
locking point.
Vegetable box and cover
• Up the cover and apart then pull out the
vegetable box at the mid-point and up and
and pull to apart.
• Up and apart as showed.
(concerned model : SR-
5066/5466/5866)
1
2
1
2
1
2
1
2
