Samsung Electronics 41
11-1 Refrigerator inside lamp replacement
11. Disassemble and assemble method
1) Remove the screw with (+) driver and
push the cover to the arrow direction and
apart.
2) Remove out the lamp to the arrow direction
and replace with new one. ( Left & Right )
3) Insert the front of the cover first and screw
it.
11-2 Freezer inside lamp replacement
• Grab the the salient part of cover and pull
it down to apart. Replace the 220V/15W
lamp and insert front of cover first and
then fix it.
