52 Samsung Electronics
1. Remove the cover with the back latch pressed.
2. Pull out the lamp.
3. After replacing the lamp, assemble the front latch of
cover and then connect the back latch.
4. Plug in and check if power is cut off or not by pressing
the R-door switch.
Warning
Always take out the power plug when replacing the refrigerator lamp. There is the danger of
electric shock.
9. Disassembly & Assembly
1. Replacement of refrigerator lamp
To Next Page
