CN803 3711-004386 CONNECTOR-HEADER BOX,3P,1R,2mm,ANGLE,SN
CN804 3722-001055 JACK-PHONE 5P/2C,3.6mm,AG,BLK,#16-22
CN805 3711-004270 CONNECTOR-HEADER BOX,2P,1R,2MM,ANGLE,SN
CN806 3722-000143 JACK-PHONE 1P(VER),3.4mm,AG,BLK,NO
CN807 3711-002046 CONNECTOR-HEADER 3WALL,12P,1R,1.25mm,SMD
D700 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,600mA,SOT
D701 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,600mA,SOT
D702 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,600mA,SOT
D703 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,600mA,SOT
D704 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,600mA,SOT
D800 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D801 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D802 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D803 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D804 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D805 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D806 0403-000277 DIODE-ZENER MMBZ5226B,3.3V,5%,225mW,SOT
D808 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
D809 0403-001052 DIODE-ZENER RD8.2MB,8.2V,7.7-8.64V,200mW
FT700 2903-000181 FILTER-CERAMIC TR,5.5MHz,-,TP,TPS5.5
FT701 2903-000129 FILTER-CERAMIC TR,4.5M/4.72MHZ,-,TP,
IC700 2904-001203 FILTER-SAWAV 38.9MHz,SIP5K,ST,16.9dB,B/G
IC701 2904-001143 FILTER-SAWAV 38.9MHz,SIP5K,TP,18dB,B/G,L
IC702 2904-001195 FILTER-SAWAV 38.9MHz,SIP5K,TP,17.9dB,B/G
IC703 1204-001161 IC-IFCIRCUIT TDA9810T,SOP,24P,300MIL,PLA
IC704 1002-001185 IC-D/ACONVERTER TDA8444T,6BIT,SOP,16P,30
IC800 1201-001201 IC-POWERAMP 7268,DIP,16P,335MIL,DUAL,32d
IC801 1204-001567 IC-SOUNDPROCESSOR MSP3440G,QFP,80P,PLA
IC803 1203-001488 IC-POSI.FIXEDREG. 7805,T0-252,3P,PLAS
IC804 1203-001488 IC-POSI.FIXEDREG. 7805,T0-252,3P,PLAS
IC805 1203-001816 IC-POSI.FIXEDREG. 78M08,TO-252,3P,PLAS
IC806 1203-001815 IC-POSI.FIXEDREG. 78M09,TO-252,3P,PLAS
L700 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L701 2701-000101 INDUCTOR-AXIAL 1.2uH,10%,2.5x3.4mm
L702 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L703 2701-000114 INDUCTOR-AXIAL 10uH,10%,2.5x3.4mm
L704 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L705 2701-000114 INDUCTOR-AXIAL 10uH,10%,2.5x3.4mm
L706 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L707 2701-000120 INDUCTOR-AXIAL 12uH,10%,2.5x3.4mm
L708 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L709 2701-000299 INDUCTOR-AXIAL 13UH,10%,2.5X3.4MM
L800 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L801 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L802 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
L803 2703-001778 INDUCTOR-SMD 3.3UH,20%,3.2X2.5X2.2MM
MP1.0 BN41-00025A PCB-SUB ML17NS,FR-4,1.6
7 Electrical Parts List
SyncMaster 150MP 7-17
Loc. No. Code No. Description Specification Remarks
