2 Product Specifications
2-2 SyncMaster 150MP
2-2 Pin Assignments
Sync
Type
Pin No.
15-Pin Signal Cable Connector
Separate Composite Sync-on-green
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
No Connection
GND-Sync/Self Test
GND
DDC Data
Horizontal sync
Vertical sync
DDC Clock
Red
Green
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
No Connection
GND-Sync/Self Test
GND
DDC Data
H/V-Sync
Not Used
DDC Clock
Red
Green + H/V Sync
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
Not Used
GND-Sync/Self Test
GND
DDC Data
Not Used
Not Used
DDC Clock
