2 Product Specifications
SyncMaster 150MP 2-5
Table 2-1. Timing Chart (Continued)
Timing No.
Originator
Mode Name
Resolution (HxV)
19
VESA
1024/75Hz
1024x768
32
MAC
640/67Hz
640x480
33
MAC
832/75Hz
832x624
Frequency
Total time
Active time
Blank time
Border (L / R)
Data time
Front porch
Sync. width
Back porch
Sync. polarity
60.023kHz
16.660µs
13.003µs
3.657µs
0.000µs
13.003µs
0.203µs
1.219µs
2.235µs
Positive
35.000kHz
28.571µs
21.164µs
7.407µs
0.000µs
21.164µs
2.116µs
2.116µs
3.175µs
Negative
49.726kHz
20.110µs
14.524µs
5.586µs
0.000µs
14.524µs
0.559µs
1.117µs
3.910µs
Negative
VERTICAL
HORIZONTAL
Frequency
Total time
Active time
Blank time
Border (T / B)
Data time
Front porch
Sync. width
Back porch
Sync. polarity
75.029Hz
13.328ms
12.795ms
0.533ms
0.000ms
12.795ms
0.017ms
0.050ms
0.466ms
Positive
66.667Hz
15.000ms
13.714ms
1.286ms
0.000ms
13.714ms
0.086ms
0.086ms
1.114ms
Negative
74.551Hz
13.414ms
12.549ms
0.865ms
0.000ms
12.549ms
0.020ms
0.060ms
0.784ms
Negative
Dot Clock 78.750MHz 30.240MHz 57.284MHz
Sync. Type
Scan Type
*
Separate
N/I
Separate
Composite
Sync.-on-G
N/I
Separate
Composite
Sync.-on-G
N/I
