Samsung SyncMaster 153V

User’s Manual
Specifications
General (153V)
General
Model Name 153V
LCD Panel
Size 15.0 inch diagonal
Display area 304.1 (H) x 228.1 (V)
Pixel Pitch 0.297 (H) x 0.297 (V)
Type a-si TFT active matrix
Synchronization
Horizontal 31 ~ 61 kHz
Vertical 56 ~ 75 Hz
Display Color
16,294,277 Colors
Resolution
Optimum resolution 1024 x 768@60Hz
Maximum resolution 1024 x 768@75Hz
Input Signal, Terminated
RGB Analog 0.7 Vpp positive at 75 ohms
Separate H/V sync, TTL level positive or negative
Maximum Pixel Clock
80 MHz
Power Supply
AC 90 ~ 264 VAC, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
Power Consumption
32W (Maximum)
Dimensions (WxDxH)
353.5 x 57.0 x 280.5 mm (Without Stand)
353.5 x 150 x 345.0 mm (After folding the Stand)
Weight
VESA Mounting Interface
75mm x 75mm (for use with Specialty(Arm) Mounting hardware.)
Viewing Angle 140/120(L,R/T,B)
3.4kg (With Simple Stand)
