3 Disassembly and Reassembly
3-2 213T
6. Disconnect LVDS cable from the panel and
disconnect invertor cable from the shield.
7. Disconnect function cable from the shield and
lift up the panel.
8. Remove 4 screws from the panel.
(right and left)
3-2 Replacement Order of Lamp Assemblies
1. Remove the lamp wire holding tape from
the metal chassis on the bottom side.
1-1. Taking out the lamp wire from
the lamp wire holder.
To Next Page
