Connecting the Monitor
1.
Connect the power cord for your monitor to the
POWER
on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
2-1.
Using the D-sub (Analog) connector on the video card.
Connect the signal cable to the 15-pin,
RGB
port on the back of your monitor.
[RGB]
2-2.
Using the DVI (Digital) connector on the video card.
Connect the DVI cable to the
DVI(HDCP)
port on the back of your monitor.
[DVI(HDCP)]
2-3.
Connected to a Macintosh.
Connect the monitor to the Macintosh computer using the D-sub connection cable.
2-4.
In the case of an old model Macintosh, you need to connect the monitor using a special Mac
adapter.
3.
Turn on your computer and monitor. If your monitor displays an image, installation is
complete.
Connecting to Other devices
This monitor allows the user to connect it to such input devices as a DVD player, a VCR
