Specifications
General
General
Model Name
LCD Panel
Size 22 inch (55 cm)
Display area 473.76 mm (H) x 270.9 mm (V)
Pixel Pitch 0.282 mm (H) x 0.282 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.7M
Resolution
Optimum resolution 1680 x 1050@60 Hz
Maximum resolution 1680 x 1050@60 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
146 MHz (Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
Dimensions (W x H x D) / Weight (Simple Stand)
505.5 x 331.5 x 72.0 mm / 19.9 x 13.1 x 2.8 inch (Without Stand)
505.5 x 417.2 x 217.5 mm / 19.9 x 16.4 x 8.6 inch (With Stand), 5.35 kg / 11.8 lbs
Dimensions (W x H x D) / Weight (HAS Stand)
505.5 x 331.5 x 67.6 mm / 19.9 x 13.1 x 2.7 inch (Without Stand)
505.5 x 375.4 x 200.0 mm / 19.9 x 14.3 x 7.9 inch (With Stand), 6.35 kg / 14.0 lbs
53
