Samsung SyncMaster 755DF - Page 44

Loc. No. Code No. Description Specification Remarks
C557 2401-001643 C-AL “0.68uF,20%,50V,GP,TP,5x11mm,5”
C601 2301-001195 “C-FILM,MPPF” “150nF,10%,275VAC,BK,26x16.5x7,”
C602 2301-001195 “C-FILM,MPPF” “150nF,10%,275VAC,BK,26x16.5x7,”
C603 2201-000024 “C-CERAMIC,DISC” “4.7nF,20%,250VAC,Y5U,TP,16x7,7”
C604 2201-000024 “C-CERAMIC,DISC” “4.7nF,20%,250VAC,Y5U,TP,16x7,7”
C607 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
C608 2401-003391 C-AL “220uF,20%,450V,GP,BK,25x50,10”
C609 2401-000971 C-AL “22uF,20%,50V,WT,TP,6x11mm,5mm”
C610 2301-000284 “C-FILM,PEF” “47nF,5%,100V,TP,8.5x12.5mm,5mm”
C611 2401-000613 C-AL “1uF,20%,50V,WT,TP,5x11,5”
C612 2401-000613 C-AL “1uF,20%,50V,WT,TP,5x11,5”
C613 2201-000129 “C-CERAMIC,DISC” “0.1nF,10%,1kV,Y5P,TP,7x4,5”
C614 2201-000019 “C-CERAMIC,DISC” “10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5”
C615 2201-000291 “C-CERAMIC,DISC” “1nF,10%,500V,Y5P,TP,7.5x3.5,5”
C616 2201-000023 “C-CERAMIC,DISC” “2.2nF,20%,125V,Y5U,TP,11x7,5”
C617 2201-000023 “C-CERAMIC,DISC” “2.2nF,20%,125V,Y5U,TP,11x7,5”
C618 2401-000039 C-AL “1000uF,20%,16V,GP,TP,10x16,5”
C619 2201-000469 “C-CERAMIC,DISC” “0.33nF,10%,500V,Y5P,TP,5.5x3,5”
C620 2401-000540 C-AL “150uF,20%,63V,LZ,TP,10x25,5”
C621 2401-001585 C-AL “47uF,20%,50V,WT,TP,8x11.5,5”
C622 2401-000039 C-AL “1000uF,20%,16V,GP,TP,10x16,5”
C623 2401-000039 C-AL “1000uF,20%,16V,GP,TP,10x16,5”
C624 2201-000210 “C-CERAMIC,DISC” “0.12NF,10%,1KV,Y5P,TP,6.3X4MM,5”
C625 2305-001041 “C-FILM,MPEF” “220nF,5%,63V,TP,7.5x4.5x13.5,5”
C626 2401-000037 C-AL “470uF,20%,16V,GP,TP,8x11.5,5”
C627 2401-000142 C-AL “1000uF,20%,16V,WT,TP,10x20,5”
C630 2401-001561 C-AL “47uF,20%,35V,WT,TP,8x11.5,5”
C631 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
C635 2201-000019 “C-CERAMIC,DISC” “10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5”
CIS BH39-00014A CBF-HARNESS
“1P,280MM,RED,UL1032,AWG22,YFH800-1,BS201R”
CIS BH39-00145A CBF SIGNAL “ATT,1500MM,15P/6P,7P,IVORY(IV01),-,D-SUB/MALE”
CIS BH68-00001A LABEL/MARK-CDT “ART-PAPER 100G,-,WHT,BLK,-,ALL,CDT”
CIS BH72-00025A GUIDE-POWER “CDA4507,ABS+PC,5V,IV16,-,-”
CIS BH72-00026A SHAFT-POWER “CDA4507,ABS+PC,5V,IV16,-,-”
CIS BH72-00078A SHEET-LMF “DP17L,AL+PC,-,-,0.5,-”
CIS BH73-60304C RUBBER-SUPPORT “DP15LT,CR V0,GRAY,-,14*7*10,-,-”
CIS BH75-00031B UNIT/FRAME-BOTTOM “DF17JS,SECC T1.0,-,-,-”
CIS BH71-00008A SHIELD-BOTTOM “CDA4507,SECC ,T1.0,-,-”
CIS BH71-00059A EARTH-PLATE/FRONT “DF17JS,STS 301,T0.15,-,-”
CIS BH46-00001P “MICOM-S/W,DF17KS” “DP-FLAT(70KHz),-,-”
CIS 0205-001027 OIL-SILICON “G746,-,-”
CIS 1204-001508 IC-VERTICAL DEF.
“KA2142,SIP,10P,-,PLASTIC,35V,15W,-20TO+70C,ST,VERTICAL DEFLECTION”
CIS 6006-001008 SCREW-ASS’Y MACH “WSP,BH,+,M3,L10,ZPC(YEL),SWRCH”
CIS 6021-000118 NUT-HEXAGON “1C,M3,ZPC(YEL),SM20C”
CIS BH62-00003A HEAT/SINK-V.IC “-,T1,-,A1050S,DA/DB”
CIS BH13-00004A IC-HYBRID “-,DP104C,TO-220-5L,5P,POWER SWITCH,-,-”
CIS BH61-00004A SPRING-TR “CDA,CDB,SUS304,T0.5,-,-,-,-”
7 Electrical Parts List
SyncMaster 753DF/755DF 7-3
