Samsung SyncMaster 755DF - Page 45

CIS BH62-00004A HEAT/SINK-POWER “-,T1,-,A1050S,DA/DB”
CIS BH62-20001B RUBBER “CSQ4357,W25*L20*T0.45,-,-,-,-”
CIS 0205-001027 OIL-SILICON “G746,-,-”
CIS 0505-001309 FET-SILICON “IRF630,N,200V,10A,0.4OHM,100W,TO-220”
CIS 6006-001008 SCREW-ASS’Y MACH “WSP,BH,+,M3,L10,ZPC(YEL),SWRCH”
CIS 6021-000118 NUT-HEXAGON “1C,M3,ZPC(YEL),SM20C”
CIS BH62-30024A HEAT/SINK-TR “SPC,T1,SN,CFX1577L”
CIS 0205-001027 OIL-SILICON “G746,-,-”
CIS 0402-001255 DIODE-RECTIFIER “DTV56F,1.5KV,10A,TO-220AC,BK”
CIS 0502-000465 TR-POWER “KTD2058-Y,NPN,25W,TO-220IS,ST,”
CIS 0502-001170 TR-POWER “2SC5440,NPN,60000mW,TOP-3E,ST,-8”
CIS BH61-00004A SPRING-TR “CDA,CDB,SUS304,T0.5,-,-,-,-”
CIS BH61-70003A SPRING “CVT4857,STS304-W1/2H,T0.5,W3.8”
CIS BH62-00015A HEAT SINK-FBT “A1050S,T1.0,T1.0,-,-”
CIS 0205-001027 OIL-SILICON “G746,-,-”
CIS 0505-001181 FET-SILICON “IRF634A,N,250V,8.1A,450mohm,74”
CIS BH61-00004A SPRING-TR “CDA,CDB,SUS304,T0.5,-,-,-,-”
CIS BH62-00016A HEAT SINK-TR “A1050S,T1.0,-,DP17MO”
CN201 3711-003895 CONNECTOR-HEADER “BOX,13P,1R,2mm,STRAIGHT,SN”
CN202 3711-003873 CONNECTOR-HEADER “BOX,7P,1R,2mm,STRAIGHT,SN”
CN304 3711-000197 CONNECTOR-HEADER “1WALL,3P,1R,2.5mm,STRAIGHT,SN”
CN403 3711-003989 CONNECTOR-HEADER “NOWALL,4P,1R,8mm,STRAIGHT,SN”
CN501 BH71-40300A PIN-HINGE “-,BRASS,D2.36,SN,HEAT/SINK”
CN601 3721-001028 PLUG-AC POWER “3P,-,-,NI”
CN603 3711-000217 CONNECTOR-HEADER “1WALL,3P,1R,3.96mm,STRAIGHT,SN”
D301 0402-000274 DIODE-RECTIFIER “UF4004,400V,1A,DO-41,TP”
D401 0402-000274 DIODE-RECTIFIER “UF4004,400V,1A,DO-41,TP”
D402 0402-000006 DIODE-RECTIFIER “1N4007GP,1000V,1A,DO-41,TP”
D403 0402-000006 DIODE-RECTIFIER “1N4007GP,1000V,1A,DO-41,TP”
D404 0402-000006 DIODE-RECTIFIER “1N4007GP,1000V,1A,DO-41,TP”
D405 0402-000208 DIODE-RECTIFIER “EK-04,40V,1.5A,DO-41”
D406 0402-001025 DIODE-RECTIFIER “ERD07-15,1.5KV,1.5A,-,TP”
D407 0402-001118 DIODE-RECTIFIER “UF1G,400V,1.2A,DO-204AL,TP”
D409 0402-001295 DIODE-RECTIFIER “GUR460L-5700,600V,4A,DO-201AD,BK”
D410 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
D411 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
D412 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
D413 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
D420 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
D421 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
D422 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
D431 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
D432 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
D501 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
D502 0402-000017 DIODE-RECTIFIER “RGP02-12,1200V,0.5A,DO-204AL,T”
D503 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
D504 0402-000546 DIODE-RECTIFIER “TVR10G,400V,1.0A,DO-41,TP”
7 Electrical Parts List
7-4 SyncMaster 753DF/755DF
Loc. No. Code No. Description Specification Remarks
