R610 2001-000114 R-CARBON(S) “180KOHM,5%,1/2W,AA,TP,2.4X6.4MM”
R611 2001-001079 R-CARBON(S) “15OHM,5%,1/2W,AA,TP,2.4X6.4MM”
R612 2003-000738 R-METAL OXIDE(S) “56Kohm,5%,2W,AA,TP,4x12mm”
R614 2001-001107 R-CARBON(S) “220ohm,5%,1/2W,AA,TP,2.4x6.4mm”
R615 2001-001088 R-CARBON(S) “1KOHM,5%,1/2W,AA,TP,2.4X6.4MM”
R616 2001-001108 R-CARBON(S) “22KOHM,5%,1/2W,AA,TP,2.4X6.4MM”
R617 2001-001037 R-CARBON(S) “0.39OHM,5%,1/2W,AA,TP,2.4X6.4MM”
R618 2001-000429 R-CARBON “1KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R619 2003-000471 R-METAL OXIDE(S) “10ohm,5%,2W,AA,TP,4x12mm”
R620 2001-000354 R-CARBON “150KOHM,5%,1/4W,AA,TP,2.4X6.4MM”
R621 2001-000989 R-CARBON “820KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R625 2001-000786 R-CARBON “47KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R630 2001-000786 R-CARBON “47KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R631 2001-000429 R-CARBON “1KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R632 2001-000290 R-CARBON “10KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
RL601 3501-001111 RELAY-POWER “12Vdc,250mW,5A,1FormA,15mS,5mS”
S/BTM+PCB
6003-000010 SCREW-TAPTITE “BWH,+,B,M3,L10,ZPC(YEL),SWRCH1”
SK501 4715-000001 SURGE ABSORBER “1KV,+50-10%,-,-,”
SW201 3404-000244 SWITCH-TACT “15V,20mA,90-170gf,7.5x7mm,SPST”
SW202 3404-000244 SWITCH-TACT “15V,20mA,90-170gf,7.5x7mm,SPST”
SW203 3404-000244 SWITCH-TACT “15V,20mA,90-170gf,7.5x7mm,SPST”
SW204 3404-000244 SWITCH-TACT “15V,20mA,90-170gf,7.5x7mm,SPST”
SW401 3406-000002 SWITCH-ROTARY “36Vdc,200mA,SP3T,-”
SW601 3403-001050 SWITCH-PUSH “30V,0.3A,SPDT,ON-OFF,PC BORD T”
T401 BH26-00027A TRANS-HOR.DRIVE “35.0MH,-,EI 1916,PL-3,-,310UH,-”
T402 BH26-00028A TRANS-H.LINEARITY
“5.2UH,6P,DR1425(C:5.0),YL-81,5.2UH/68.0MH,-,HL-1425E”
T501 BH26-00035A TRANS-FBT “1.0MH,13P,FUR3658,HV45,-,-,FM1059,FEA831”
T502 BH26-00057A TRANS-FOCUS
“3.8MH MIN,10P,EI-2218,(SB-5S),SB-5S,3.8MH/225MH MIN,40UH MAX,-”
T601 BH26-00059A TRANS-POWER
“350UH,18P,EER 3541,PL3,PM2,7.0UH MAX.,0.22OHM,-”
T602 BH26-30302S TRANS-SYNC. “3-1(250UH),-,-,SB-5S,UU1116,3-”
TH601 1404-000002 THERMISTOR-PTC “9ohm,20%,-,-,TR,RECT,-”
TH602 1404-001020 THERMISTOR-NTC “8ohm,15%,-,17mW/C,BK”
TP501 6042-000002 EYELET “ID1.5,OD2,L3.1,SN,BSS3-E/EH”
X201 2801-000005 CRYSTAL-UNIT “8MHz,50ppm,28-AAM,S,35ohm,TP”
ZD201 0403-000361 DIODE-ZENER “UZ6.2BSB,6.2V,5.99-6.24V,500mW”
ZD202 0403-000361 DIODE-ZENER “UZ6.2BSB,6.2V,5.99-6.24V,500mW”
ZD203 0403-000361 DIODE-ZENER “UZ6.2BSB,6.2V,5.99-6.24V,500mW”
ZD204 0403-000361 DIODE-ZENER “UZ6.2BSB,6.2V,5.99-6.24V,500mW”
ZD205 0403-000361 DIODE-ZENER “UZ6.2BSB,6.2V,5.99-6.24V,500mW”
ZD502 0403-001068 DIODE-ZENER “UZ4.7BSA,4.7V,4.47-4.65V,500mW”
ZD601 0403-000361 DIODE-ZENER “UZ6.2BSB,6.2V,5.99-6.24V,500mW”
ZD602 0403-001068 DIODE-ZENER “UZ4.7BSA,4.7V,4.47-4.65V,500mW”
7 Electrical Parts List
7-12 SyncMaster 753DF/755DF
Loc. No. Code No. Description Specification Remarks
To Next Page
