Loc. No. Code No. Description Specification Remarks
7 Electrical Parts List
SyncMaster 753DF/755DF 7-13
BD102 3301-000011 CORE-FERRITE BEAD “AA,3.5x1.0x5.7mm,1500,2375G”
BD103 3301-000011 CORE-FERRITE BEAD “AA,3.5x1.0x5.7mm,1500,2375G”
C102 2401-000603 C-AL “1uF,20%,50V,GP,TP,5x11,5”
C103 2401-000037 C-AL “470uF,20%,16V,GP,TP,8x11.5,5”
C105 2301-000010 “C-FILM,PEF” “100nF,5%,100V,TP,11.5x12.5mm,5”
C106 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
C107 2401-000010 C-AL “220uF,20%,16V,GP,-,6.3x11mm,2.”
C108 2401-000049 C-AL “47uF,20%,100V,WT,TP,10x16,5”
C109 2201-000177 “C-CERAMIC,DISC” “10nF,10%,50V,Y5P,TP,12x3.5,5”
C110 2401-000025 C-AL “100uF,20%,16V,GP,TP,6.3x11,5”
C112 2401-000603 C-AL “1uF,20%,50V,GP,TP,5x11,5”
C113 2301-000287 “C-FILM,PEF” “5.6nF,5%,100V,TP,10.5x12.5x6.5”
C116 2301-000188 “C-FILM,PEF” “1nF,5%,100V,TP,10.5x12.5x6.5,5”
C117 2301-000188 “C-FILM,PEF” “1nF,5%,100V,TP,10.5x12.5x6.5,5”
C118 2201-000471 “C-CERAMIC,DISC” “0.33nF,10%,50V,Y5P,TP,4x3.5,5”
C119 2201-000291 “C-CERAMIC,DISC” “1nF,10%,500V,Y5P,TP,7.5x3.5,5”
C120 2201-000285 “C-CERAMIC,DISC” “1nF,10%,1kV,Y5P,TP,8x5,5”
C121 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
C123 2201-000019 “C-CERAMIC,DISC” “10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5”
C124 2301-000148 “C-FILM,PEF” “10nF,5%,100V,TP,7x3.2x7mm,5mm”
C125 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
C126 2201-000117 “C-CERAMIC,DISC” “1.8nF,10%,500V,Y5P,TP,8.5x3,5”
C128 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
C151 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
C152 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
C160 2401-000031 C-AL “47uF,20%,16V,GP,TP,5x11,5”
CB01 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
CB02 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
CB04 2401-000055 C-AL “1uF,20%,160V,WT,TP,3x11,5mm”
CB05 2301-000010 “C-FILM,PEF” “100nF,5%,100V,TP,11.5x12.5mm,5”
CB06 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
CB07 2201-000146 “C-CERAMIC,DISC” “0.1nF,5%,50V,SL,TP,5x3.5,5”
CB08 2201-000411 “C-CERAMIC,DISC” “0.27nF,10%,50V,Y5P,TP,4x3.5,5”
CG01 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
CG02 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
CG04 2401-000055 C-AL “1uF,20%,160V,WT,TP,3x11,5mm”
CG05 2301-000010 “C-FILM,PEF” “100nF,5%,100V,TP,11.5x12.5mm,5”
CG06 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
CG07 2201-000146 “C-CERAMIC,DISC” “0.1nF,5%,50V,SL,TP,5x3.5,5”
CG08 2201-000411 “C-CERAMIC,DISC” “0.27nF,10%,50V,Y5P,TP,4x3.5,5”
CIS BH75-00047A UNIT/SHIELD-VIDEO/CAP “CL17LO,SPTE T0.3,-,-,-”
CIS BH71-00006B SHIELD-VIDEO/CAP “CL17LO,SPTE,0.2,-,-”
CIS BH71-10311A EARTH-PLATE
CIS BH75-00192H UNIT/SHIELD-VIDEO “DEL,-,SPTE,-,-,14””,15””,17””,-”
CIS BH61-00002A SPRING-VIDEO “CDB7907,STS H14 ,T1.0,-,-,-,NORMAL CDT”
CIS BH71-00007A SHIELD-VIDEO “CDA4507,SPTE,T0.2,-,-”
CIS BH72-00024A HOLDER-VIDEO “CDA4507,ABS+PC,5V,IV16,-,NORMAL CRT”
7-2 Video PCB Parts
