CIS BH73-00014A HOLDER-RUBBER(NORMAL) “DEL,SILICON V2,GRAY,-,-,-,NORMAL”
CIS 0205-001027 OIL-SILICON “G746,-,-”
CIS 6006-001008 SCREW-ASS’Y MACH “WSP,BH,+,M3,L10,ZPC(YEL),SWRCH”
CIS 6021-000118 NUT-HEXAGON “1C,M3,ZPC(YEL),SM20C”
CIS BH13-00003A IC-HYBRID “-,LM2437,TO-220,9P,CRT DRIVER,0 TO 6.0V,-”
CIS BH62-00006A HEAT SINK-VIDEO “-,A1050S T2.0,-,DB”
CN101 3711-004228 CONNECTOR-HEADER “BOX,6P,1R,2MM,ANGLE,SN”
CN102 BH39-00015A CBF-HARNESS
“13P/14P,200MM,WHT/BLK/RED/BLU,UL1007,AWG26,SMH200-13/YBNH200-14”
CR01 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
CR02 2201-000119 “C-CERAMIC,DISC” “100nF,+80-20%,50V,Y5V,TP,8x3,5”
CR04 2401-000055 C-AL “1uF,20%,160V,WT,TP,3x11,5mm”
CR05 2301-000010 “C-FILM,PEF” “100nF,5%,100V,TP,11.5x12.5mm,5”
CR06 2202-002009 “C-CERAMIC,MLC-AXIAL” “100nF,+80-20%,50V,Y5V,TP,2.3X3”
CR07 2201-000146 “C-CERAMIC,DISC” “0.1nF,5%,50V,SL,TP,5x3.5,5”
CR08 2201-000411 “C-CERAMIC,DISC” “0.27nF,10%,50V,Y5P,TP,4x3.5,5”
D102 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DB01 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DB02 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DB03 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
DB04 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
DB05 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DG01 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DG02 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DG03 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
DG04 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
DG05 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DR01 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DR02 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
DR03 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
DR04 0401-000004 DIODE-SWITCHING “1SS244,250V,200mA,DO-34,TP”
DR05 0401-000005 DIODE-SWITCHING “1N4148,100V,200MA,DO-35,TP”
EY1 6042-000002 EYELET “ID1.5,OD2,L3.1,SN,BSS3-E/EH”
EY2 6042-000001 EYELET “ID2.2,OD2.7,L3.1,SN,BSS3-E/EH”
EY3 6042-000001 EYELET “ID2.2,OD2.7,L3.1,SN,BSS3-E/EH”
EY4 6042-000002 EYELET “ID1.5,OD2,L3.1,SN,BSS3-E/EH”
G2 BH71-40300A PIN-HINGE “-,BRASS,D2.36,SN,HEAT/SINK”
GND BH71-40300A PIN-HINGE “-,BRASS,D2.36,SN,HEAT/SINK”
HS103 BH99-00004B “ASSY,HEAT/SINK” “H/S VIDEO,SCREW+NUT,LM2437,-,-,OIL SILICON,-,-”
IC101 1204-001646 IC-OSD PROCESSOR “KB2502,DIP,32P,600MIL,PLASTIC,-,-,-20to75C,ST,-”
JP103 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP109 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP116 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP117 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP119 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP122 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP123 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP124 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
7 Electrical Parts List
7-14 SyncMaster 753DF/755DF
Loc. No. Code No. Description Specification Remarks
