Loc. No. Code No. Description Specification Remarks
JP127 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP128 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP133 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP134 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP136 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP137 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP140 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP142 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP146 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP147 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP148 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP150 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP151 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
JP152 BH39-40305U CBF HARNESS “,52MM,-,-,AWG22(0.6PI),-,-,-,-”
L101 2701-000112 INDUCTOR-AXIAL “100uH,10%,3x7mm”
L103 2701-000164 INDUCTOR-AXIAL “27uH,10%,4.2x9.8mm”
LB01 2701-000172 INDUCTOR-AXIAL “330nH,10%,3x7mm”
LG01 2701-000172 INDUCTOR-AXIAL “330nH,10%,3x7mm”
LJP1 BH39-40306D CBF-HARNESS “,80MM,BLK,1015,AWG22,-,-,-,-,-”
LR01 2701-000172 INDUCTOR-AXIAL “330nH,10%,3x7mm”
MP1.2 BH41-00058A PCB-VIDEO “TP17LT,PHENOL,-,1.6T*247*330MM,-”
Q102 0501-000122 TR-SMALL SIGNAL “2N3904,NPN,625mW,TO-92,TP,100-”
QB01 0501-000140 TR-SMALL SIGNAL “2N5551,NPN,625mW,TO-92,-,80-25”
QB02 0501-000138 TR-SMALL SIGNAL “2N5401,PNP,625mW,TO-92,TP,60-2”
QG01 0501-000140 TR-SMALL SIGNAL “2N5551,NPN,625mW,TO-92,-,80-25”
QG02 0501-000138 TR-SMALL SIGNAL “2N5401,PNP,625mW,TO-92,TP,60-2”
QR01 0501-000140 TR-SMALL SIGNAL “2N5551,NPN,625mW,TO-92,-,80-25”
QR02 0501-000138 TR-SMALL SIGNAL “2N5401,PNP,625mW,TO-92,TP,60-2”
R101 2001-000522 R-CARBON “22KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R102 2001-000281 R-CARBON “100OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R103 2001-001138 R-CARBON(S) “390OHM,5%,1/2W,AA,TP,2.4X6.4MM”
R104 2001-001138 R-CARBON(S) “390OHM,5%,1/2W,AA,TP,2.4X6.4MM”
R107 2001-000429 R-CARBON “1KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R108 2001-000812 R-CARBON “5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R109 2001-000563 R-CARBON “27KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R114 2001-000780 R-CARBON “470OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R115 2001-000577 R-CARBON “2KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R116 2001-000290 R-CARBON “10KOHM,5%,1/8W,AA,TP,1.8X3.2MM”
R117 2001-000515 R-CARBON “220OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R118 2001-000857 R-CARBON “560OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R119 2001-000857 R-CARBON “560OHM,5%,1/8W,AA,TP,1.8X3.2MM”
R120 2002-001022 R-COMPOSITION “30MOHM,5%,1/4W,AA,TP,2.5X6.5MM”
R123 2001-000432 R-CARBON “1MOHM,5%,1/4W,AA,TP,2.4X6.4MM”
R124 2001-000034 R-CARBON “220OHM,5%,1/4W,AA,TP,2.4X6.4MM”
RB01 2001-000969 R-CARBON “75OHM,5%,1/8W,AA,TP,1.8X3.2MM”
RB02 2001-000969 R-CARBON “75OHM,5%,1/8W,AA,TP,1.8X3.2MM”
RB03 2001-000780 R-CARBON “470OHM,5%,1/8W,AA,TP,1.8X3.2MM”
7 Electrical Parts List
SyncMaster 753DF/755DF 7-15
