User’s Manual 57
Specifications
General
General
Model Name SyncMaster 757NF
Picture Tube
Type 17"(43cm) Natural Flat (40.6cm viewable)
Deflection angle 90°
Dot Pitch 0.25 mm (
Uni-pitch
Aperture Grill )
Screen type Aluminized tri-color phosphor dot trio with black matrix.
Anti-doming invar shadow mask.
Multi-layer coated with anti-static
Maximum Flicker-Free Resolution
1600 Dots, 1200 Lines @76Hz Flicker-Free Display
Active Display
Horizontal 3
1
2 ±
3
mm
Vertical 2
3
4 ±
3
mm
Synchronization
Horizontal 30 ~ 96 kHz
Vertical 50 ~ 160 Hz
Input Signal Definition
Video Signal RGB, Analog 0.7 Vpp positive at 75 ohms
Sync Signal Separate H/V sync, Composite, SOG (Sync-On-Green)
TTL level, positive or negative
Display Color
Unlimited
