Specifications
General
General
Model Name
SyncMaster 933SN
LCD Panel
Size 18.5 inch (47 cm)
Display area 409.8 mm (H) x 230.4 mm (V)
Pixel Pitch 0.3 mm (H) x 0.3 mm (V)
Synchronization
Horizontal
40 ~ 80 kHz
Vertical 50 ~ 75 Hz
Display Color
16.7M
Resolution
Optimum resolution 1360 x 768@60 Hz
Maximum resolution 1360 x 768@60 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
89 MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
Dimensions (W x H x D) / Weight (Simple Stand)
453.3 x 299.3x 69.8 mm / 17.9 x 11.8x 2.8inch (Without Stand)
453.3 x 354.9 x176.6 mm / 17.9 x13.9 x6.9 inch (With Stand), 3.65 kg / 9.8 lbs
VESA Mounting Interface
75.0 mm x 75.0 mm (For use with Specialty(Arm) Mounting hardware.)
