Samsung SyncMaster 997MB Plus - Specifications; General Technical Specifications

General
General
Model Name SyncMaster 997MBplus
Picture Tube
Type 19"(48cm) DynaFlat (45.8cm viewable)
Deflection angle 90 °
Dot Pitch 0.20mm (Horizontal)
Screen type Aluminized tri-color phosphor dot trio with black matrix.
Anti-doming invar shadow mask.
Multi-layer coated with anti-static.
Resolution
Optimum resolution 1280 x 1024 @ 85Hz
Maximum resolution 1600 x 1200
Active Display
Horizontal 352 ± 3 mm
Vertical 264 ± 3 mm
Synchronization
Horizontal 30 ~ 96 kHz
Vertical 50 ~ 160 Hz
Input Signal Definition
Video Signal RGB, Analog 0.7 Vpp positive at 75 ohms
Sync Signal Separate H/V sync, TTL level, positive or negative
Display Color
Unlimited
Maximum Pixel Clock
250 MHz
Power Supply
AC 90 ~ 264 VAC rms, 60/50 Hz ± 3Hz
