POWER port
Connect the power cord for your monitor to the POWER port on the back of
the product.
USB OUT port
DOWN(USB downstream port)
Connect the
DOWN
port of the USB monitor and a USB device with the
USB cable.
UP(USB upstream port)
Connect the
UP
port of the monitor and the USB port of the computer
with the USB cable.
USB IN port
Connect the
port of the monitor and the USB of the computer with the
USB cable.
RGB IN port
Connect the D-sub cable to the 15-pin, RGB IN port on the back of your mon-
itor.
Kensington Lock
The Kensington lock is a device used to physically fix the system when using
it in a public place. (The locking device has to be purchased separately.) For
using a locking device, contact where you purchase it.
Note
The
location of the Kensington Lock may be different depending on its model.
