Specifications
General
General
Model Name SyncMaster LD190N
LCD Panel
Size 18.5 inch (47 cm)
Display area 409.8 mm (H) x 230.4 mm (V)
Pixel Pitch 0.3 mm (H) x 0.3 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 50 ~ 75 Hz
Display Color
16.7 M
Resolution
Optimum resolution
1360 x 768@60 Hz
Maximum resolution 1360 x 768@60 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
89 MHz (Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
Dimensions (W x H x D) / Weight (Simple Stand)
450.2 x 295.8 x 72.0 mm (17.7 x 11.6 x 2.8 inch) (With Stand) / 4.7 kg(10.4 lbs)
Environmental considerations
Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % ~ 80 %, non-condensing
Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)
