3-2
3. Disassembly and Reassembly
Description Picture Description Screws
2. 26" C4000 :
Remove the 13 screws of rear-cover.
22" C4000 :
Remove the 10 screws of rear-cover.
6003-000133
6003-001003
3. Lift up the rear-cover.
4. Remove the left and right speaker.
5. Lift up the stand link.
Remove the 4 screws of bracket stand link.
6003-000133
To Next Page
