2-1
2. Product specications
2. Product specications
2-1. Feature & Specications
Model UN46B8000XF
Feature
Digital-TV, RF, 4-HDMI, 1-Component, 1-AV, USB1, USB2 (HDD is available only in USB1), D-SUB, Internet@TV
Brightness : 500cd/m
2
Contrast Ratio : 5000000:1
Response time : 3ms
Dynamic contrast, Super-PVA
PIP(in HDMI 1, 2, 3, 4, component, PC Mode and Sub picture is available in TV analog and digital mode)
�
�
�
�
�
�
Specications
Item Description
LCD Panel TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
46-Inch viewable, 0.53025(H) × 0.53025(W) mm pixel pitch
Scanning Frequency Horizontal : 67.5KHz (typ)
Vertical : 60Hz (typ)
Display Colors 1.07 billion colors
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 148.5MHz
Active Display
Horizontal/Vertical
40.083 × 22.547 inches (1018.08 (H) × 572.67(V) mm)
AC power voltage & Frequency AC 110V ~ 220V, 60 Hz
Power Consumption < 220W (< 0.1W, stand by)
Dimensions
44.5 × 10.9 × 29.8 inches (1131 × 277 × 757 mm)_with stand
44.5 × 1.17 × 27 inches (1131 × 29.9 × 688 mm)_without stand
Set (W x D x H)
Weight (Set) 50.26lbs (22.8kg)_with stand
38.68lbs(18kg)_without stand
TV System Tuning Frequency Synthesize (Refer to detailed Frequency Table)
System ATSC, NTSC 3.58
Sound NTSC-M, AC-3 Digital
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio spec. - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -10dB ~ + 10dB
- TREBLE Control Range : -10dB ~ +10dB
- Output Frequency : RF : ~ 15 kHz
A/V : ~ 20 kHz
Note: Anynet+, Media Play, Internet@TV
