1. Precautions (1-1 ~ 1-2)
2. Product Specification (2-1 ~ 2-4)
2-1 Product Specification (2-1)
2-2 Chassis Product Specification (2-2)
2-3 Accessories Supplied with Camcorder (2-3)
3. Alignment and Adjustments (3-1 ~ 3-20)
3-1 VCR Adjustment (3-1)
3-2 Camera Adjustment (3-3)
3-3 LCD Adjustment (3-7)
3-4 Deck Adjustment (3-11)
4. Disassembly and Reassembly (4-1 ~ 4-16)
4-1 Cabinet and PCB (4-1)
4-2 Deck (4-5)
5. Exploded View and Parts List (5-1 ~ 5-20)
5-1 Ass’y Chassis (5-2)
5-2 Ass’y Left (5-4)
5-3 Ass’y LCD (5-6)
5-4 Ass’y Right (5-8)
5-5 Ass’y Rear (5-10)
5-6 Ass’y CVF (5-12)
5-7 Ass’y Case Left (5-13)
5-8 Ass’y Front (5-14)
5-9 Ass’y Housing (5-15)
5-10 Mechanical Parts (Main Chassis) (5-16)
5-11 Mechanical Parts (Sub Chassis) (5-18)
6. Electrical Parts List (6-1 ~ 6-14)
7. Block Diagram (7-1 ~ 7-4)
7-1 All Block Diagram (7-1)
7-2 IC102 Block Diagram (7-2)
7-3 IC201 Block Diagram (7-3)
8. Wiring Diagram (8-1 ~ 8-2)
