Samwha DSP CTL - Order Information and Accessories

Digital Motor Protection Realy
DSP-C Serie
Order Form
DIV
Description
Remark
1
2
3
4
5
6
Terminal Type : Basic reference code +T : eg.XXXXXX -T
COL
COM
10
70
B
Z
7
ZCT
P
Panel Mounting Type / Unified Meter type
5~6A with external CT
Panel Flush Mounting Type / Seperated Meter type
0.5~10A
5~70A
24VAC/DC
100VAC ~ 240VAC(90VDC ~ 370VDC)
50/60Hz
Embedded ZCT
Optional by customer
not used for external CT type
Accessory
External CT
Cable
ZCT
DSP - CABLE-12
DSP - C1
DSP - CC
DSP - C2
DSP - C3
DSP - C4
DSP - CABLE-18
DSP - CABLE-30
DSP - CABLE-50
DSP - ZCT - XX
*100mA/1.5mA
*XX : Inner diameter of ZCT
5m
3m
1.8m
1.2m
3CT/Rectangular, 400/5
3CT/Rectangular, 300/5
3CT/Rectangular, 200/5
3CT/Rectangular, 150/5
3CT/Rectangular, 100/5
DSP-Type-Current rating-Z7(Control Voltage)-ZCT(Embedded ZCT)-P(Customer optional)
eg. Reference Code : DSP-COL-10-CC-Z7 → COL combined with external CT 150/5, control voltage:
100VAC~240VAC,50/60Hz, possible to use external ZCT
