Samwha DSP DSP-VIP-PM - Page 22

3 REVERSE START
4
Remote Control
Sensor/must be
matched logic #1
to start and stop a
motor
PC
5 Meter run(MCC)
6 External Fault Input
Temperature A,B,B+ PT100
State
RED
Operating
3 Tone Colour LED
Green
Power ON :
stop state
Yellow Trip
Output
MAIN TRIP 97-98
VOLTAGE TRIP 27-28
Changeable to ALLc
AUX TRIP 07-08
4~20mA +, -
SC/F~MC/R
C1 COMMON
SC/F Starting contactor/forward contactor
MC/R Main contactor/reverse contactor
*Close(motor start)-Open (trip)
* Close(motor start) is coworked with logic input
*Trip is operated together with main trip
▶ Display window image
→ Panel Flush Mounting Type : Display meter
