DSP-VIP-PL/PM
Voltage-Current based Digital Multi-function Motor Protection
Relay
1.System Construction
○ DSP-VIP-PL/Panel Mounting Type
○ DSP-VIP-PM/ Panel Flush Mounting Type
Cable/RS232
Comm.Module
Converter
Display Meter
#1
#2
RS232
OR
RS232
RS232
Converter
Comm.Module
OR
#1
#2
#32
Loader
