Samwha DSP DSP-VIP-PM - Current Range Table for External CT

17.Current Range Table for external CT
Range
Number of
CT turn in
itself
Preset in "ct" mode
Preset in
"cto"
mode
Remarks
(ct ratio)
0.2A~70A
1 *Without external CT
1t
70 Type,Wide Range
1 *With external CT:0.2~6A
5t
0.4A~10A 1 2(10:5)
5A
*With external CT,
Secondary rating of CT is
5A
*CT ratio to preset is
1~600
0.6A~15A 1 3(15:5)
0.8A~20A 1 4 (20:5)
1.2A~30A 1 6 (30:5)
1.6A~40A 1 8 (40:5)
2A~50A 1 10(50:5)
2.4A~60A 1 12 (60:5)
3A~75A 1 15 (75:5)
4A~100A 1 20(100:5)
4.8A~120A 1 24(120:5)
3.6A~150A 1 30(150:5)
8A~200A 1 40(200:5)
10A~250A 1 50(250:5)
12A~300A 1 600(300:5)
16A~400A 1 80(400:5)
20A~500A 1 100(500:5)
24A~600A 1 120(600:5)
30A~750A 1 150 (750:5)
32A~800A 1 160(800:5)
40A~1000A 1 200(1000:5)
48A~1200A 1 240(1200:5)
60A~1500A 1 300(1500:5)
80A~2000A 1 400(2000:5)
100A~2500A 1 500(2500:5)
120A~3000A 1 600(3000:5)
