SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 24 / 63
7. D-REGISTER Description
D-Register is group of communication data to monitor and control all status of TEMI2500.
D-Register is grouped by consecutive 100 addresses based on its concerned function as shown below.
D-Register address Group Name Description Read Write
D0001~D0099 PROCESS General operation process information
D0100~D0199 FUNCTION Operating Function setting
D0200~D0299 RESERVATION Time & Reserve operation setting
D0300~D0399 ON/OFF SIGNAL ON/OFF signal setting
D0400~D0499 INNER SIGNAL INNER signal setting
D0500~D0599 ALARM SIGNAL ALARM signal setting
D0600~D0699 SEG ALARM SIGNAL SEGMENT ALARM signal setting
D0700~D0799 TIME SIGNAL TIME signal setting
D0800~D0899 COMMUNICATION Communication concerned information
D0900~D0999 PICTURE USER SCREEN setting
D1000~D1099 PID1 P.I.D setting-1
D1100~D1199 PID2 P.I.D setting-2
D1200~D1299 INPUT Sensor Input setting
D1300~D1399 OUTPUT Control& retransmission Output setting
D1400~D1499 DO CONFIG1 DO(Digital Output) Relay setting-1
D1500~D1599 DO CONFIG2 DO(Digital Output) Relay setting-2
D1600~D1699 DI CONFIG1 DI(Digital Input) setting
D1700~D1799 DI CONFIG2 DI NAME input-1
D1800~D1899 DI CONFIG3 DI NAME input-2
D1900~D1999 INITIAL1 Initial system setting-1
D2000~D2099 INITIAL2 Initial system setting-2
D2100~D2199 PROGRAM Program pattern profile setting
D2200~D2299 PATTERN INFO Pattern profile information
D2300~D3999 FILE1 ~ FILE17 Recorded Trend file information
D-Register is composed of hexadecimal 4 digit (2-Byte).
○ : Available to read / write over all designated address range.
△ : Available to read / write in part of designated address range.
◈ : Not available to read / write over all designated address range.
