Samwontech TEMP2500 Communications Manual

SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 25 / 63
7.1 PROCESS
PROCESS group consists of fundamental parameter information concerned with operation process and status.
Below table describes the detail Bit Map information of some parameter that indicates its status by Bit.
█ Bit Map information of TEMP2500
NOW.STS IS.STS TS.STS ALM.STS SEGALM.STS ONOFF.STS ADERR.STS
BIT
(D0010) (D0012) (D0014) (D0016) (D0018) (D0020) (D0022)
0 RESET IS1 TS1 ALM1 SEGALM1 T1 +OVER
1 FIX IS2 TS2 ALM2 SEGALM2 T2 -OVER
2 PROG IS3 TS3 ALM3 SEGALM3 T3 S.OPN
3 HOLD IS4 TS4 ALM4 SEGALM4 T4
4 WAIT IS5 TS5 T5
5 AT IS6 TS6 T6
6 IS7 TS7 T7
7 IS8 TS8
8
9
10
11
12
13
14
15
DOCTR.STS CTR.STS DO.STS1 DO.STS2 DI.DATA SYS.STS
BIT
(D0024) (D0026) (D0028) (D0029) (D0030) (D0031)
0 RUN RUN DO1 DO17 DI1 DISP.COMERR
1 WAIT WAIT DO2 DO18 DI2 IO.COMERR
2 UP UP DO3 DO19 DI3 SD.INSERT
3 DOWN DOWN DO4 DO20 DI4
4 SOAK SOAK DO5 DO21 DI5
5 FEND FEND DO6 DO22 DI6
6 PTEND PTEND DO7 DO23 DI7
7 1REF 1REF DO8 DO24 DI8
8 2REF 2REF DO9 DO25 DI9
9 DO10 DO26 DI10
10 DO11 DO27 DI11
11 DO12 DO28 DI12
12 DO13 DO29 DI13
13 DO14 DO30 DI14
14 DO15 DO31 DI15
15 DO16 DO32 DI16
