█ Bit Map status information D-Register
D-Reg. Symbol Descriptions
D0010 NOW.STS Current operation status information.
D0012 IS.STS INNER signal generating status information.
D0014 TS.STS TIME signal generating status information.
D0016 ALM.STS ALARM signal generating status information.
D0018 SEGALM.STS SEGMENT ALARM signal generating status information.
D0020 ONOFF.STS ON/OFF signal generating status information.
D0022 ADERR.STS Error status out of control range.
D0024 DOCTR.STS Other DO signal generating status information.
D0026 CTR.STS Displayed DO signal status information on 2
nd
Oper screen
D0028 DO.STS1
D0029 DO.STS2
Actual generating Do signal status through I/O board
D0030 DI.DATA DI Error outbreak status information.
D0031 SYS.STS
The main control and display or the main control and
I / O relay board Communication error occurs and the SD
card used in the information indicates.
█ Common process information D-Register for both PROG / FIX
D-Reg. 기 호 내 용
D0001 NPV Current PV
D0003 NSP Current SP
D0005 MVOUT Current control output
D0007 CPIDNO Currently running PID number
D0034 RUN.TIME_H Process time (Hour)
D0035 RUN.TIME_M Process time (Minute)
D0036 RUN.TIME_S Process time (Second)
█ PROGRAM operation process information D-Register
D-Reg. 기 호 내 용
D0040 RUN.PTNO Currently running program pattern number
D0041 RUN.SEGNO Currently running program segment number
D0044 NOW.PT.RPT Count of current Repeat operation at running pattern
D0045 TOTAL.PT.RPT Total Programmed Count of Repeat op. at running pattern
D0048 NOW.SEG.RPT Count of current Repeat operation at running segment
D0049 TOTAL.SEG.RPT Total Programmed Count of Repeat op. at running segment
D0052 NOW.SEGTM_H Process time(High) of currently running segment
D0053 NOW.SEGTM_L Process time(Low) of currently running segment
D0054 TOTAL.SEGTM_H Programmed total time(High) of currently running segment
D0055 TOTAL.SEGTM_L Programmed total time(Low) of currently running segment
D0060 PREV.TSP Target Set Point of the preceding segment
D0061 NOW.TSP Target Set Point of the current segment
D0065 USED PATTERN Total number of programmed pattern
D0066 USED SEGMENT Total number of programmed segment
