Samwontech TEMP2500 Communications Manual

SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 27 / 63
7.2 FUNCTION Group
FUNCTION group consists of setting parameter D-register related with operational function and process.
█ Common Operational Function setting D-Register for both PROG / FIX
D-Reg. Symbol Descriptions
D0112 FUZZY FUZZY Function (0:0FF, 1:ON)
D0121 KEYLOCK KEYLOCK Function (0:0FF, 1:ON)
D0126 DRAW.CYCLE Sampling time for recording on internal memory
D0127 PV.GRP_RECORD Activating to record on internal memory (0:0FF, 1:ON)
D0130 REC.OP Activating to record on SD memory card (0:0FF, 1:ON)
D0131 REC.CYCLE Sampling time for recording on SD memory card
D0132 BACK.ITEM BACKUP ITEM setting(0:PTN, 1:PARA, 2:ALL)
D0133 BACK.DIR BACKUP DIRECTION setting
D0136 AT Carrying out Auto-Tuning (0:0FF, 1:ON)
D0150 PV.FONT PV FONT select (0:HEAD, 1:NORM, 2:ART)
D0151 BUZ.ONOFF Buzzer sound ( 0: UNUSE, 1: USE )
D0152 LIGHT.OFFTM Backlight ON time
D0160 UTAG_USING Tags enable (0:OFF, 1:ON)
D0161 ~ D0163 UTAG.NAME1~ UTAG.NAME3 Tag name is set up to 6 digits.
█ PROGRAM Operation & Function setting D-Register
D-Reg. Symbol Descriptions
D0100 SET.PTNO Pattern Number to run program operation
D0140 WAIT.USE WAIT Function (0:UNUSE, 1:USE )
D0142 WAIT_ZONE WAIT ZONE setting
D0144 WAIT_TIME WAIT TIME setting
D0146 WAIT.METHOD Target of WAIT function (0:ALL, 1:SEG )
█ FIX Operation & Function setting D-Register
D-Reg. Symbol Descriptions
D0104 FIX.TSP Set Point on FIX operation
D0110 SLOPE UP/DOWN Setting the slope
D0114 TIME.OP TIME OPERATION (0:UNUSE, 1:USE)
D0115 TIME.OP_H HOUR setting for TIME OPERATION
D0116 TIME.OP_M MINUTE & SEC setting for TIME OPERATION
