SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 30 / 63
7.4 ON/OFF SIGNAL Group
This setting parameter D-register group is used to establish 6 ON/OFF SIGNALs.
█ ON/OFF SIGNAL setting D-Register
D-Reg. Symbol Description
D0301 T1.LSP Low SP for ON/OFF SIGNAL T1
D0302 T1.MSP Middle SP for ON/OFF SIGNAL T1
D0303 T1.HSP High SP for ON/OFF SIGNAL T1
D0304 T1.HDV High zone Deviation for operating Point at High Zone T1
D0305 T1.LDV Low zone Deviation for operating Point at Low Zone T1
.
.
.
.
.
.
.
.
.
D0336 T6.LSP Low SP for ON/OFF SIGNAL T6
D0337 T6.MSP Middle SP for ON/OFF SIGNAL T6
D0338 T6.HSP High SP for ON/OFF SIGNAL T6
D0339 T6.HDV High zone Deviation for operating Point at High Zone T6
D0340 T6.LDV Low zone Deviation for operating Point at Low Zone T6
