7.7 SEGMENT ALARM SIGNAL Group
This setting parameter D-register group is used to establish 8 SEGMENT ALARM signals.
█ SEGMENT ALARM signal setting D-Register
D-Reg. Symbol Descriptions
D0601 SA1.TYPE Type of SEGMENT ALARM signal 1
D0602 SA1.POINT Target Point of SEGMENT ALARM signal 1
D0603 SA1.H_POINT Limit High point of SEGMENT ALARM signal 1
D0604 SA1.L_POINT Limit Low point of SEGMENT ALARM signal 1
D0605 SA1.HYS Hysteresis of SEGMENT ALARM signal 1
D0606 SA1.DYT DELAY TIME of SEGMENT ALARM signal 1
.
.
.
.
.
.
.
.
.
D0643 SA8.TYPE Type of SEGMENT ALARM signal 8
D0644 SA8.POINT Target Point of SEGMENT ALARM signal 8
D0645 SA8.H_POINT Limit High point of SEGMENT ALARM signal 8
D0646 SA8.L_POINT Limit Low point of SEGMENT ALARM signal 8
D0647 SA8.HYS Hysteresis of SEGMENT ALARM signal 8
D0648 SA8.DYT DELAY TIME of SEGMENT ALARM signal 8
