1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 34 / 63
7.8 TIME SIGNAL Group
This setting parameter D-register group is used to establish 19 TIME SIGNALs.
█ TIME SIGNAL setting D-Register
D-Reg. Symbol Descriptions
D0701 TS2DYTM_H DELAY TIME (HOUR) of generating TIME SIGNAL 2.
D0702 TS2DYTM_L DELAY TIME (MIN. & SEC.) of generating TIME SIGNAL 2.
D0703 TS2KPTM_H OPER.TIME (HOUR) to keep generating TIME SIGNAL 2.
D0704 TS2KPTM_L OPER.TIME (MIN. & SEC.) to keep generating TIME SIGNAL 2.
.
.
.
.
.
.
.
.
.
D0773 TS20DYTM_H DELAY TIME (HOUR) of generating TIME SIGNAL 20.
D0774 TS20DYTM_L DELAY TIME (MIN. & SEC.) of generating TIME SIGNAL 20.
D0775 TS20KPTM_H OPER.TIME (HOUR) to keep generating TIME SIGNAL 20.
D0776 TS20KPTM_L OPER.TIME (MIN. & SEC.) to keep generating TIME SIGNAL 20.
