SAND PS1016 - Page 4

 Adjustment state of internal parameters:
a)Press Shift key for more than 5 seconds in measuring and the system enters into adjustment state of
internal parameters;
b)Each time the Shift key is pressed, internal parameters are output sequentially. Symbols of internal
parameters are displayed on upper display window and currently set parameter values, lower display
window;
c)Use Shift key, Up key and Down key to modify currently set parameter values;
d)Press Shift key to confirm and store newly set values and call the next parameter;
e)Press Shift key for more than 5 seconds or no key is pressed for more than one minute, the system
will automatically return from the adjustment state of internal parameters back to measuring state;
f)Press AC key and meanwhile, point press Shift key, pressure zero can be cleared. Press AC key for
more than 5 seconds and the actual pressure zero of last calibration can be recovered;
g)Press Calibration key and point press Shift key simultaneously, the system goes to automatic
calibration. Please refer to related section on calibration for system pressure.
Interior parameter list
Symbol name Enactment range explain Ex-factory initial value
measurement
range
10.00MPa~100.0MPa Pressure measurement rating
supplementary transducer
measurement range
Pressure
division value
0.01MPa
0.02MPa
0.05MPa
The least solution Of Pressure
Measurement Rating
recommended
0-20Mpadv setup 0.01
0.02MPa
Pressure upper
limit
00.0099.99MPa
Set up the alarm value of pressure
upper limit
REN80%
Pressure alarm
difference
0~2.00MPa
Setup for Pressure alarm
difference
0.00MPa
Temperature
upper limit
Temperature 0~
measurement range
Set up the alarm value of
temperature upper limit
80% of temperature
measurement range
Digital lock
0000: can modify
parameter. The panel
keys are available.
0001: can modify
parameter. The panel
keys are unavailable
but conversion key.
The panel keys and all parameters
can be locked up through the
setup of digital lock
0000
Orders explain: please order according to the explain as follows
The basic productTemperature pressure gauge Type PS1016
Function
Explain for functions
1double deck four-digit pipe display the actual value of
pressure and temperature separately
4choice for measurement range panel
2relay outputpressure and temperature upper limit 5choice for least resolution
3automatically calibration system 6parameter setup and lockup function
