SAND PS1016 - Page 5

Pressure measurement range
measurement range number measurement range number
010MPa 010 040MPa 040
015MPa 015 050MPa 050
020MPa 020 060MPa 060
025MPa 025 070MPa 070
030MPa 030 080MPa 080
035MPa 035 0100MPa 100
Pressure outputDirect ratio with temperature and pressure, and recorders and PID adjustors can use it.
Output format number Output format number
No output 200 0~10mAmaximum 6V 203
0~5Vmaximum 20mV 201 0~20mAmaximum 6V 204
1~5Vmaximum 20mV 202 4~20mAmaximum 6V 205
Alarm
figure The first digit The second digit The third digit
0 No alarm No alarm output No alarm signal lamp
1 Pressure upper limit Relay output LBD signal lamp
2 Temperature upper limit Controlled silicon output
3 Pressure and temperature upper limit Voltage pulse output
Note: If the number of the item is 311, the first digit expresses the alarm of Pressure and temperature upper
limit; the second digit expresses relay switch output; and the third digit expresses LBD signal lamp.
Controlled silicon two-end output 600V/5
Order format
PS1016 – [
Pressure range code] – [Output signal code] – [Alarm parameters]
Example:
PS1016-050-205-311
Pressure range of 0 ~ 50 Mpa, the output signal to 4 ~ 20 mA, alarm parameters for 311.
Self-calibration for system zero pressure: connect high-temperature fusion pressure transducer with
PS1016 intelligent temperature & pressure gauge according to operation manual. Properly connect 220 V
AC power supply. Press ‘cal’ key and point press Shift key simultaneously after system POST, and then the
system starts fully automatic self-calibration. Calibration lamp starts flashing. Press Shift key all the time
during calibration until calibration is completed and the system returns automatically back to working state.
