S&A CWFL-800 - CWFL-1500 Specifications

CWFL-800/1000/1500 Series
13
CWFL-1500
Model
CWFL-1500AN
CWFL-1500BN
Voltage
AC 1P 220 V
AC 1P 220 V
Frequency
50 Hz
60 Hz
Current
3.4~16 A
Compressor power
1.73 KW
1.69 KW
2.35 HP
2.30 HP
Nominal cooling
capacity
17623 Btu/h
17145 Btu/h
5.17 KW
5.03 KW
4441 Kcal/h
4320 Kcal/h
Electric assisted power
400W+600W
Refrigerant
R-22/R-410a
Refrigerant charge
950g
900g
Precision
±0.5℃
Reducer
Capillary
Protection
Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power
0.55 KW
Tank capacity
15 L
Inlet and outlet
Rp1/2”+Rp1/2”
Max. pump lift
45M
★ Max. pump flow
70 L/min
N.W
86 Kgs
G.W
96 Kgs
Dimension
78 X 47 X 89 cm (L X W X H)
Package dimension
87X 60 X 109 cm (L X W X H)
★ The max. pump flow is obtained by testing the pump individually on
test criteria GB/T 3216-2005.criteria GB/T 3216-2005.
