S&C Alduti-Rupter Instructions For Operation

S&C ELECTRIC COMPANY
•
Chicago
S&C ELECTRIC CANADA LTD.
•
Toronto
s
783-501
INSTRUCTION SHEET
Page 2 of 4
August 29, 1983
S&C Alduti-Rupter ® Switches
Three-Pole
Indoor Transmission (4.8 kv through 34.5 kv)
INTRODUCTION — Continued
initial fault-closing operation, offer no assurance of an
ability to subsequently carry or interrupt rated cur-
rent—much less any expectation of tolerating a second
fault closing.
The Alduti-Rupter Switch interrupts the circuit
without
external arc or flame.
No oil or vacuum is used. The arc is
entirely contained and extinguished within the air-filled
interrupter.
When the arc is established both the trailer and liner of
the interrupter yield deionizing gases which quickly
quench the arc. The small radial clearance between the
liner and trailer ensures efficient deionizing action even
when interrupting low currents.
For any given position of the blade there is a predeter-
mined position of the interrupter contacts. Special care
has been given to coordination of the blade and interrupter
contacts to prevent flashover during opening operations.
The external gap between the line side and load side of the
switch always exceeds the gap
within the interrupter at
the time of circuit interruption.
The interrupter is powered directly by the opening or
closing movement of the blade. Springs are not relied on
for contact separation, but are used solely as positive
open-closed detention devices. High-speed travel is pro-
vided, instead, by a speed-multiplying straight-line linkage.
Operating Mechanisms
Three-pole Alduti-Rupter Switches—Indoor Distribution
are furnished with operating mechanisms for manual oper-
ation by means of chain-coupled, direct-coupled, or pipe-
coupled handles.
Chain-Coupled Handles are used for the majority of
applications, typically with single- and multi-bay metal-
enclosed switchgear installations, and permit switch oper-
ation from the front.
Direct-Coupled Handles are used for single-bay metal-
enclosed switchgear or vault applications where side oper-
ation is desired.
Pipe-Coupled Handles are used only for application
(generally in vaults) where the positioning of the handle,
relative to the switch, does not permit linear coupling, i.e.,
where bellcranks must be used.
