Sandel SN3500 Pilot's Guide

APPENDIX
82005-PG, REV M SANDEL SN3500 PILOT’S GUIDE PAGE 17-1
CHAPTER 17 SN3500 WITHOUT LED LIGHTING
This chapter contains images that reflect data color coding that is
specific to early SN3500s that are not equipped with an LED light
source.
Display Areas (Figure 2-2)
Parked Heading Bug
Upper
display
area
Lower
display
area
Primary
display
area
APPENDIX
82005-PG, REV M SANDEL SN3500 PILOT’S GUIDE PAGE 17-2
Parked Course Pointer
Inner Course and Vertical Deviation Indicators
Outer Course and Vertical Deviation Indicators
Inner C DI
Inner VDI
Outer CDI
Outer VDI
Back Course Needle
