SandenVendo V21 621 - Page 119

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230336
POWER BOX ASSEMBLY
ITEM
NO.
DESCRIPTION
QTY
REQ
PART NO.
115V 60Hz
230V 50Hz
1
POWER BOX HOUSING
1
1236202
1148515
2
RELAY
2
1128801
1128801
3
CLAMP
1
324099-3
324099-3
4
CORDSET
1
1184889
1124938/1124939
4
CORDSET HVV
1
1124281
5
TRANSFORMER
1
1111201
1121932
6
FUSEHOLDER
1
1128474
1128474
7
0.8 AMP FUSE (NOT SHOWN)
1
1053864
1053864
8
POWER HARNESS
1
1123444
1123444
9
FUSE LABEL
1
1126640
1126640
10
HARNESS, RELAY, LED (NOT SHOWN)
1
1204233
1204233
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-20 & C-21.
V21
Cabinet Parts | C-19
